Key Words: galvanized wire, PVC coated, chain link mesh, electro galvanized, black annealed
Classification: Steel Wire
Product Highlights:
| Model NO. | PVC-PE-ChainLink | Technique | Hot Dipped / Electro Galvanizing |
|---|---|---|---|
| Application | Chain Link Fence, Gabion, Mesh Protection | Alloy or Not | Non-alloy |
| Zinc Coating | Black Annealed / Electro Galvanized / Hot-Dip Galvanized | Coating Type | Plastic / PE / PVC |
| Inner Diameter | 2.0–4.0 mm | Outer Diameter | 2.2–5.0 mm |
| Tensile Strength | 390–1400 MPa | Elongation | 4%–10% |
| Transport Package | Coil | Weight/Coil | 1–800 kg |
| Origin | China | HS Code | 7217200000 |
| Inner Dia. Range (mm) | Outer Dia. Range (mm) | Tensile (MPa) | Elongation (%) | Zinc Coating (g/m²) | Packing Size | Weight/Package |
|---|---|---|---|---|---|---|
| 2.00–4.00 | as requested | 390–500 | 10 | Black Annealed / Electro Galvanized / Hot Dipped | Coil | 1 kg–800 kg |
| 600–900 | 4 | |||||
| 1000–1400 | 4 |
| Nominal Wire Diameter | Tolerance (mm) |
|---|---|
| over 2.00mm up to and incl. 3.00mm | ±0.02 |
| over 3.00mm up to and incl. 4.00mm | ±0.03 |
| Tensile Grade | % Carbon | % Phosphorus | % Manganese | % Silicon | % Sulphur |
|---|---|---|---|---|---|
| Soft | 0.05–0.15 | 0.035 | 0.5–1.00 | 0.10–0.34 | 0.041 |
| Standard | 0.45–0.50 | 0.032 | 0.5–1.00 | 0.10–0.34 | 0.041 |
| High | 0.59–0.63 | 0.035 | 0.5–1.10 | 0.10–0.35 | 0.045 |
| Extra-High | 0.65–0.83 | 0.035 | 0.5–1.10 | 0.10–0.35 | 0.045 |
Key features of PVC/PE Glued Coated Galvanized Wire:
Packing Options:
✔️ Coil sizes from 1 kg to 800 kg
✔️ Custom packing and labeling
✔️ Plastic film wrapping, PE bags, or woven bags as required
Delivery Time: 15–30 working days
We are a professional manufacturer with our own factory and production lines. Zhongbo Steel Products Co., Ltd. has specialized in galvanized steel wire and strip production since 2003.
Our total production capacity exceeds 110,000 tons per year, with a stable monthly capacity of about 9,000 tons for various galvanized steel wires and strips.
Over 80% of our products are exported worldwide. Our main export markets include Southeast Asia, the Middle East, Europe, South America, and North America.
Please provide the required wire diameter, tensile strength, zinc coating weight, coil or spool size, packaging requirements, and destination port. For special applications like cable armouring, please specify any additional standards or certifications needed.
For trial orders, we accept small quantities like one coil for quality checking. For regular orders, we recommend full container loads (FCL) to ensure safe transportation and cost-effectiveness.
T/T (30% advance, 70% balance before shipment), L/C at sight, or negotiable based on order size and buyer profile.
Yes, samples under 2 kg are available free of charge; courier cost is to be covered by the customer.
Yes. Third-party inspection (SGS, BV, or customer-designated agent) is available before shipment, and the inspection cost will be borne by the buyer.
