Galvanized Steel Wire for Filter-Mesh and Fine-Screen Weaving (0.15–1.0 mm)
- Diameter range: 0.15–1.0 mm (fine-wire, Zhongbo legacy range)
- Input wire for woven/welded filter mesh, fine screens and industrial wire cloth — not finished filter mesh
- Fine diameter, ovality, cast and helix controlled for stable weaving/crimping
- Electro- or hot-dip galvanized, with coating type/mass by mesh process
- Precision spool feed matched to your weaving or welding equipment
Made to order to your diameter, coating, tensile grade and standard — request a quote for price, minimum order quantity and lead time.
Specifications
| Model NO. | ZB-FILTER-WIRE |
| Technique | Fine-wire drawing and galvanizing |
| Application | Filter-mesh, fine-screen, woven fabric and selected welded-mesh conversion |
| Alloy or Not | Non-alloy steel unless the approved order states otherwise |
| Standard | Customer specification; general wire/coating standards for test methods (national fine-wire standards confirmed for edition and scope before naming) |
| Surface Treatment | Electro- or hot-dip galvanized (process by diameter) |
| Dimensions Tolerance | Fine-wire tolerance, ovality, cast and helix to approved specification |
| Delivery Time | Quoted after diameter, mechanical properties, coating, packing, quantity and destination are confirmed |
| Material | Low-carbon steel; grade to the approved tensile/formability requirement |
| Specification | 0.15–1.0 mm round wire |
| Available | OEM / ODM / manufacture to drawing, subject to technical review |
| Transport Package | Precision spools/reels compatible with weaving or welding equipment |
| Trademark | Zhongbo Steel |
| Origin | Xinzheng, Henan, China |
| HS Code | Confirmed by material, finish, cross-section and destination |
| Production Capacity | Confirmed with the quotation |
Tensile Strength
Confirmed tensile runs about 320–500 MPa; mesh weavers usually hold a narrower band within that to balance wire strength with crimping and weaving formability. Elongation, cast/helix and weldability are added when measured, and a trial spool is recommended so pay-off, crimping/weaving, break rate and finished-mesh geometry can be evaluated before a bulk order.
Features
- Fine diameter and ovality control
- Formable mechanical condition for weaving/crimping
- Uniform galvanized surface with controlled coating
- Stable cast/helix and precision spool pay-off
- Custom sizes and spool formats for mesh equipment
- Batch inspection and trial-spool support
Packaging & Shipping
We build a spool matrix — flange, barrel, traverse, bore, net weight and winding — and protect fine-wire ends with clean, dry packing that avoids flange damage, stating whether level winding is standard.
- Small precision spools
- DIN or customer weaving reels
- Larger converter reels where feasible
- Palletized cartons or crates with moisture barrier
Use cases
- Woven filter mesh and fine screens
- Industrial wire cloth
- Fine welded mesh where the grade/coating is suitable
- Protective screens and converter products requiring fine galvanized wire
Who it is for
Wire-mesh weavers, filter-media manufacturers, screen converters, welding plants and industrial wire distributors.
Standards, certificates & inspection
Your wire and finished-mesh process requirements control; general wire and coating standards govern the test methods, and any national fine-wire standard (for example GB/T 343) is named only after its edition and scope are confirmed. We supply input wire and make no finished-filter micron-rating, pressure-drop, aperture or food/medical claim. Every batch is produced under an ISO 9001 quality management system and can ship with a mill test certificate covering diameter, tensile strength and zinc-coating weight. Third-party or pre-shipment inspection (SGS, BV or customer-appointed) is available on request.
See test reports & inspection and quality control & testing for the full documentation.
Frequently asked questions
How is this different from the general mesh-weaving wire page?
It focuses on 0.15–1.0 mm fine wire, precision spool feed and filter/screen conversion; the two pages are cross-linked.
Can you supply a narrow tensile range?
Yes, subject to production confirmation — send the weaving process, aperture/wire diameter and target tensile/elongation.
Which galvanizing process is used?
Electro or hot-dip by approved size and required coating mass; fine diameters can have different process limits.
Is Zhongbo selling finished filter mesh?
Not on this page — it is wire feedstock unless a separate finished-mesh line is verified.
Request a quote
Send your diameter, coating, standard and quantity, and we’ll reply with a quotation.
Get a QuoteTechnical documents
Download the product catalogue, or contact us for certificates and test reports.
