Stitching & Flat Wire

Flat Steel Wire for Packing, Stitching and Industrial Use

Special rectangular section — specified by width × thickness and an approved drawing, never as a diameter
Controlled edge/corner radius, camber and twist for machine feed and forming
Mechanical grade selected for forming or stiffness; tensile confirmed after flattening
Galvanized or other verified surface options (finish confirmed by process route)
Precision winding with flat orientation controlled on the reel

Made to order to your diameter, coating, tensile grade and standard — request a quote for price, minimum order quantity and lead time.

Get a Quote Download catalogue

Flat wire is a special-section product, so we present it by width × thickness and an approved drawing rather than a single diameter — a flat section is never described as a “diameter.” Buyers get width, thickness, corner/edge condition, independent width and thickness tolerances, camber, twist, tensile strength, coating and spool details. Where we produce flat wire by rolling round wire, the final section and mechanical properties are controlled after flattening, and we confirm the exact size matrix, tensile grade and surface (galvanized, copper-coated or bright) with your quotation rather than claiming every benchmark size and finish up front.

Specifications

Model NO.	ZB-FLAT
Technique	Cold drawing followed by precision flattening/rolling; coating before or after flattening per approved route
Application	Packing, stitching, clips, staples, fasteners and industrial forming
Alloy or Not	Non-alloy steel unless the approved order states otherwise
Standard	Customer drawing; relevant special-section and general wire test methods after review
Surface Treatment	Galvanized, copper-coated or bright — only where the process route is verified
Dimensions Tolerance	±0.05 mm (width/thickness); edge radius, camber and twist to approved drawing
Delivery Time	Quoted after section, mechanical properties, coating, packing, quantity and destination are confirmed
Material	Low- or medium-carbon steel selected for final strength and formability
Specification	Width × thickness — 0.80×0.50 to 2.50×0.50 mm (approved matrix)
Tensile Strength	650–950 MPa (after flattening)
Surface	Galvanized, copper-coated or bright
Available	OEM / ODM / manufacture to drawing, subject to technical review
Transport Package	Precision spools, reels, coils or straightened lengths with flat orientation controlled
Trademark	Zhongbo Steel
Origin	Xinzheng, Henan, China
HS Code	Confirmed by material, finish, cross-section and destination
Production Capacity	Confirmed with the quotation

Flat-wire size matrix

Width × thickness	Tensile range	Surface
2.50 × 0.50 mm	650–950 MPa	Galvanized / copper-coated
2.20 × 0.60 mm	650–950 MPa	Galvanized / copper-coated
2.20 × 0.70 mm	650–950 MPa	Galvanized / copper-coated
1.80 × 0.60 mm	650–950 MPa	Galvanized / copper-coated
1.50 × 0.50 mm	650–950 MPa	Galvanized / copper-coated
0.90 × 0.60 mm	650–950 MPa	Galvanized / copper-coated
0.80 × 0.50 mm	650–950 MPa	Galvanized / copper-coated

Tensile Strength

Tensile strength is published for the finished flat wire, because rolling can change the mechanical properties of the starting round wire. A broad range is divided into practical grades, and where you form staples or clips we add bend/forming performance or an approved machine trial so the grade is proven on the finished section.

Features

Section defined by width × thickness and an approved drawing
Controlled edge condition, camber and twist
Mechanical grade selected for forming or stiffness
Galvanized or other verified surface options
Precision winding and orientation for machine feed
Custom sections and trial coils subject to rolling capability

Packaging & Shipping

Flat-wire orientation is kept controlled on the reel. We state spool/reel dimensions, winding orientation, traverse, net weight, coil ID/OD, protective interleaving where needed and whether straight lengths are available.

Precision spools with flat orientation controlled
Large reels for continuous conversion
Compact coils
Straightened/cut lengths after capability confirmation

Use cases

Packing and bundling components
Flat stitching or stapling wire
Clips, formed fasteners and hardware
Industrial reinforcement or insert products

Who it is for

Staple and clip manufacturers, packaging converters, fastener producers, wire-forming companies and buyers needing custom rectangular sections.

Standards, certificates & inspection

Your drawing controls the section, tolerances, edge condition, mechanical properties and surface; general EN 10218 test methods apply, but special-section requirements must be defined. A flat section is specified by width × thickness, never as a diameter. Every batch is produced under an ISO 9001 quality management system and can ship with a mill test certificate covering diameter, tensile strength and zinc-coating weight. Third-party or pre-shipment inspection (SGS, BV or customer-appointed) is available on request.

See test reports & inspection and quality control & testing for the full documentation.

Frequently asked questions

How should flat wire be specified?

By width × thickness, independent tolerances, edge/corner condition, tensile range, surface, camber, twist and spool.

Can you make a custom section?

Yes, subject to rolling dies, minimum order, material and trial approval — send a drawing and annual demand.

Is tensile strength measured before or after flattening?

The published acceptance value applies to the finished flat wire, because rolling changes the properties of the starting round wire.

Can it be supplied galvanized?

We confirm whether coating is applied before or after rolling, the coating mass and permitted edge exposure once the process is set.

Request a quote

Send your diameter, coating, standard and quantity, and we’ll reply with a quotation.

Get a Quote

Technical documents

Download the product catalogue, or contact us for certificates and test reports.

Product catalogue (PDF)
